So we are four days into operation of the solar equipment. Right now, we are operating on a limited basis, more on that in a moment. I am not home because we are on the road, but both air conditioners, all vampire loads, and the water heater are running.
Output
We chose a system that is 10 kilowatts DC. That translates to about 8600 watts AC. The system begins generating electricity at about 9am, and reaches a peak of 8kw at around 10:30. By 1pm, the Powerwalls are fully recharged from the night before. At that point, there is no place else for the generated power to go, so system output drops to match whatever the house is using. More on that later.
We haven’t used any electricity from the grid since the sun came up on Friday morning. That indicates that I have enough panels for my house.
Storage
There are two places that I can store the power I generate. One of them is in the Powerwall, which has a total capacity of 27 KWh. Right now, I am maintaining a minimum of 30% as emergency backup, and using the rest to compensate for lower output at night or overcast conditions, or to make up for transient high loads, like when both air conditioners and the water heater are running at the same time. The advantages of using the battery are that the power stays within my home, and losing the grid means that I can still access it. The disadvantage is that the upfront cost of batteries is high.
The second place that I can store generated power is in the grid. The electric company buys my excess power in the form of credits that I can redeem when my system can’t keep up with the loads that I am placing on it- nighttime, stormy weather, or when loads simply exceed what I am producing. The advantage of this is that the upfront cost is low, but the disadvantage is that it relies on the electrical grid for redemption.
I can’t use the grid as storage because I don’t yet have permission to operate (PTO) from the power company. I should get it within two weeks after our final electrical inspection, which is supposed to be this week. So we should be fully operational by August 9.
Results So Far
Each day, we are generating between 35 and 45 kWh before panel output is reduced when the batteries are full. The solar energy being generated is directly running the house during the day, with the rest charging the Powerwalls, which run the house at night.
The water heater is using 4 kw when running, the upstairs AC is using 1.5kw, the downstairs AC uses 2.7kw, and the rest of the house uses 0.3kw. Since the ACs and water heater don’t run all of the time, the panels are more than capable at this point of keeping up by charging the batteries during the periods when the large appliances aren’t running.
Once we get our PTO, I will know more.
